| 고정포트 | 24 * 10/100/1000Base-T ports (Data), 2 * 1G uplink SFP slot ports (Data), AC input : 100~240V 50~60Hz |
| 이더넷 포트 | Port 1-24 support 10/100/1000Base-T, auto-sensing, Full/half duplex MDI/MDI-X self-adaption Port 1-8 supports QoS Data Priority Default : Normal mode, all interfaces can communicate with each other, transmission Extend : Link extension mode, 17-24 ports forced 10M, link 250meter Long reach is supported when using CAT6 cable |
| 트위스트 프로토콜 | 10BASE-T : Cat3, 4, 5 UTP(≤100 meter), 100BASE-TX : Cat5 or later UTP(≤100 meter) 1000BASE-T : Cat5e or later UTP(≤100 meter) |
| 스위치 용량 | 52Gbps |
| 버퍼 메모리 | 4M |
| 쓰루풋 | 38.68Mpps |
| MAC | 8K |
| 입력전압 | AC input : 100~240V 50~60Hz |
| Operation TEMP / Humidity | -10 ~ +50°C, 10%~90% RH Non condensing |
| Storage TEMP / Humidity | -40 ~ +70°C, 5%~95% RH Non condensing |
| 치수 ( L x H x D mm) | 440x204x44 mm |
| 설치 | 1U 19 inch rack mount |
