| 고정포트 | 24 * 10/100/1000Base-T PoE ports (Power/Data), 4 * 10G uplink SFP+ slot ports (Data), 1 * RJ45 Console port, 1 * USB port AC input : 100-240V 50-60HZ |
| 이더넷 포트 | Port 1-24 support 10/100/1000Base-T, auto-sensing, Full/half duplex MDI/MDI-X self-adaption |
| 트위스트 프로토콜 | 10BASE-T : Cat3, 4, 5 UTP(≤100 meter), 100BASE-TX : Cat5 or later UTP(≤100 meter) 1000BASE-T : Cat5e or later UTP(≤100 meter) |
| POE 포트 | Port 1 to port 24 |
| PoE Management | PoE working status, Delay start of power supply, PoE output priority configuration Scheduling of PoE operation and time, Total power limit of PoE power supply PoE output power allocation, off& af & at |
| 스위치 용량 | 128Gbps |
| 버퍼 메모리 | 95.23M |
| RAM | 128MB |
| MAC | 16K |
| 입력전압 | AC input : 100-240V 50-60HZ |
| 소비전력 | POE full load <400W |
| Operation TEMP / Humidity | 0 ~ +60°C, 10%~90% RH Non condensing |
| Storage TEMP / Humidity | -40 ~ +70°C, 10%~90% RH Non condensing |
| 치수 ( L x H x D mm) | 440X280X44 mm |
| 설치 | 1U 19 inch rack mount |
